Assembler

This project aims to create a workable risc-v/x86/arm assembler using java, this is our first stage, and then we will use it to support all the embedded-asm-syntax in our tiny kernel.

We use antlr to create parser.

Project Management

Everyone in the team should be hands-on and contribute code. We follow NoPM project management methodology. Coding oriented. We have regular weekly meeting in Kowloon Tong, around 4-6 hours, to sync up our progress and share all knowledge.

Project site

gitlab https://gitlab.com/quantr/toolchain/Assembler

facebook https://www.facebook.com/groups/491276011610560

GitLab CI/CD

We rely on gitlab ci/cd to auto build our assembler, run a full test and upload the result to https://www.quantr.hk/asmweb

Peter
Derek Tang
Cheng Darren
Ken Lam
michellechw
Ronald Park
Developer performance

Finish all knowledge preparation. Feel comfortable with Intel manual, confirm the antlr designs and whole team start translating intel basic set of instruction.

2019-06-28
to
2020-03-30

closed

Netbeans RISC-V need to support

  1. create project, generate a quantr.hk json file, all our project settings go there
  2. editor supports
    • syntax highlight
    • accurate error highlight and error message
    • code completion
  3. debugger supports
    • step over
    • step in and step out only for c code
    • run and pause
  4. Hook the netbeans debugger to our simulator
    • provide memory and register window
    • allow user modify memory and register in runtime
  5. Profiler
    • mainly base on our listing file provide additional profile information about cpu cycle
  6. Well support macro
  7. for c project, support gcc and hook their inline assembly to our assembler, and make sure linker script work
2022-06-11
to
2022-12-31

active

We need to support these macro to make our assembler really work

  1. %define
  2. %ifdef
  3. label1:
  4. %skip
  5. .byte
  6. %include
  7. times 64 db 0
  8. times 64-$+buffer db ' '
2022-06-01
to
2022-12-31

active
Peter
2. our listing format 3. macro 1. how to compile an asm file
2023-02-23
07:42:41.550
Peter
0x9b 0x97 0x37 0x00 0x000000008000002a : slliw a5,a5,0x3
2022-05-25
01:49:18.226
Peter
2021-05-20
11:09:38.520
Peter
"OUTS" instruction is stated in Intel manual, but NASM doesn't support the 'LODS', 'MOVS', 'STOS', 'SCAS', 'CMPS', 'INS', or 'OUTS' instructions, but only supports the forms such as 'LODSB', 'MOVSW', and 'SCASD' which explicitly specify the size of the components of the strings being manipulated. https://www.conradk.com/codebase/2017/06/06/x86-64-assembly-from-scratch/ **I need to know the reason**
2021-05-11
14:51:00.339
desmond ng
jmp [cx] does not exist in the list, but should we give an error if it is typed by a user? Currently only have a blank result, reason behind is not because there is no error message for such case, but because "no viable alternative input", which means the parser cant even identify it.
2020-05-18
17:14:49.296
JennyTse
![Capture](/uploads/108d346527d082e075771274e89fdfc8/Capture.PNG)
2020-01-07
08:44:47.763
desmond ng
In the function "NOP EAX" (16 bit mode), opcode is NP... which may mean no prefix. In nasm, it turns out that the instruction opcode is 66 f 1f c0. What is 66 if it is not a prefix?
2020-01-04
15:08:12.276
Kelvin Wu
POP r64 should contain REX Prefix. However, nasm doesn't output the prefix for some r64 registers. Example: 1. pop rax: quantr = 40 58, nasm = 58 2. pop r10: quantr = 41 5a, nasm = 41 5a 40, 41 in the above example are the REX prefix.
2019-12-28
03:59:34.596
Peter
Why nasm supports reg64 in LAR instruction, mismatch with intel manual?![why_lar_support_reg64](/uploads/dc2cd7210fca3c24102509880e4702e6/why_lar_support_reg64.jpg)
2019-12-06
09:50:52.067
Peter
Jenny: make sure if all instructions calling all 5 functions are still works: * initLeftToken * leftInit * initRightToken * rightInit * initCondition * initIns Kelvin: Remove byte/word/dword/qword from indirect memory access, i mean the wording before []
2019-12-01
09:51:34.796
Issac Liu
Hi, you can use this tool to compare any changes of the PE file header/section values as shown like this: ![image](/uploads/76e4d634f4d7745244746c146c50b4f7/image.png) ![image](/uploads/ab867b9a09d495dbaf7d6676e95a7757/image.png) ![image](/uploads/7389e99f9f17e020d1bfd9a8cc0477a8/image.png) download here: [LPE-DLXb_1.41_UPD.zip](/uploads/33a8cb7f7bb5b1ac02313d12f8cbcb1d/LPE-DLXb_1.41_UPD.zip)
2019-11-16
17:55:34.701
Issac Liu
Same to PEView, but I think powerful than each other. ![image](/uploads/f304c54c207a28f1f098871930e93f9e/image.png) You can download the Explorer Suite and install : [ExplorerSuite.exe](/uploads/27e6c712d825c27e319ad98744d1d438/ExplorerSuite.exe)
2019-10-27
06:24:35.515
Issac Liu
build by: **cl smallPE.c** guess that it will include import table Kernel32.dll reference [smallPE.c](/uploads/befec26eceff3131e17a905091d9b0ec/smallPE.c) [smallPE.exe](/uploads/fe1009c4e9b752d9ee7d8b94e1a838f2/smallPE.exe)
2019-10-27
06:10:24.425
Issac Liu
check the PE header field by PE View build by: **cl /nologo /c smallPE.c** **link /nologo /ENTRY:main /NODEFAULTLIB /SUBSYSTEM:WINDOWS smallPE.obj** [smallPE.exe](/uploads/c4e24b53e726d8043aa0b62bfab17c7c/smallPE.exe) [smallPE.c](/uploads/3a3cfde18ae3070bb919cf6677618eb3/smallPE.c)
2019-10-27
06:08:26.458
Peter
Enhance netbeans-antlr to support antlr file formatting
2019-10-01
16:10:14.050
Peter
1. Zero padding, cut of pad "0" 2. Jenny consolidate your code into well format, let us understand and give us tutorial next sat morning 3. Desmond: a. nasm in linux example, able to run and print hello world https://cs.lmu.edu/~ray/notes/nasmtutorial/ b. find out the minimum requirement to stuck asm program and run in linux
2019-10-01
16:09:37.663
Peter
./asm/assemble.c . Nasm just have these error, not many. ``` switch (m) { case MERR_OPSIZEMISSING: nasm_error(ERR_NONFATAL, "operation size not specified"); break; case MERR_OPSIZEMISMATCH: nasm_error(ERR_NONFATAL, "mismatch in operand sizes"); break; case MERR_BRNOTHERE: nasm_error(ERR_NONFATAL, "broadcast not permitted on this operand"); break; case MERR_BRNUMMISMATCH: nasm_error(ERR_NONFATAL, "mismatch in the number of broadcasting elements"); break; case MERR_MASKNOTHERE: nasm_error(ERR_NONFATAL, "mask not permitted on this operand"); break; case MERR_DECONOTHERE: nasm_error(ERR_NONFATAL, "unsupported mode decorator for instruction"); break; case MERR_BADCPU: nasm_error(ERR_NONFATAL, "no instruction for this cpu level"); break; case MERR_BADMODE: nasm_error(ERR_NONFATAL, "instruction not supported in %d-bit mode", bits); break; case MERR_ENCMISMATCH: nasm_error(ERR_NONFATAL, "specific encoding scheme not available"); break; case MERR_BADBND: nasm_error(ERR_NONFATAL, "bnd prefix is not allowed"); break; case MERR_BADREPNE: nasm_error(ERR_NONFATAL, "%s prefix is not allowed", (has_prefix(instruction, PPS_REP, P_REPNE) ? "repne" : "repnz")); break; case MERR_REGSETSIZE: nasm_error(ERR_NONFATAL, "invalid register set size"); break; case MERR_REGSET: nasm_error(ERR_NONFATAL, "register set not valid for operand"); break; default: nasm_error(ERR_NONFATAL, "invalid combination of opcode and operands"); ```
2019-09-30
11:11:44.731
JennyTse
how do use these instructions? ![scas](/uploads/804c4b6eec0109cf145912dc83e127b4/scas.PNG)
2019-09-18
14:54:58.160
Peter
I still don't understand what situation we need to add 0x66 ? adc al,0x12 ``` bit 16 = 14 12 bit 32 = 14 12 bit 64 = 14 12 ``` adc ax,0x1234 ``` bit 16 = 15 34 12 bit 32 = 66 15 34 12 bit 64 = 66 15 34 12 ``` adc eax,0x12345678 ``` bit 16 = 66 15 78 56 34 12 bit 32 = 15 78 56 34 12 bit 64 = 15 78 56 34 12 ```
2019-09-18
14:54:45.446
Peter
Please study windows object file format. Decode the byte like what you did last time. Please stop study ELF since i am creating a library for it. ``` global _main extern _GetStdHandle@4 extern _WriteFile@20 extern _ExitProcess@4 section .text _main: ; DWORD bytes; mov ebp, esp sub esp, 4 ; hStdOut = GetstdHandle( STD_OUTPUT_HANDLE) push -11 call _GetStdHandle@4 mov ebx, eax ; WriteFile( hstdOut, message, length(message), &bytes, 0); push 0 lea eax, [ebp-4] push eax push (message_end - message) push message push ebx call _WriteFile@20 ; ExitProcess(0) push 0 call _ExitProcess@4 ; never here hlt message: db 'Hello, World', 10 message_end: ``` To compile, you'll need NASM and LINK.EXE (from Visual studio Standard Edition) ``` nasm -fwin32 hello.asm link /subsystem:console /nodefaultlib /entry:main hello.obj ```
2019-09-12
20:22:40.724
